Overview

Specifications

		ZT50	ZT65	ZT75	ZT100	ZT120
Operating load	kg	700	1000	1050	1200	1500
Max Speed	km/h	10/15	12/18	12/18	12/18	12/18
Rated flux	L/min	60	75	80	88	88
High Flow Flux	L/min	/	/	120	120	140
Tire(track)	model	300×52.5	320×84	320×84	320×84	450×86
Rated power	Kw	36	55	55	74	103
Fuel tank capacity	L	50	80	75	90	90
Self weight bucket	kg	2800	3800	3800	4500	4800
Bucket capacity	m3	0.3	0.5	0.5	0.55	0.6
A. Overall operating height	mm	3350	3480	3480	4070	4070
B. Height to bucket hinge pin	mm	2770	2900	2900	3150	3150
C. Hheight to top of cab	mm	2050	2150	2150	2160	2160
D. Height to bottom of level bucket	mm	2603	2730	2730	2983	2983
E. Without bucket length	mm	2300	2750	2750	3000	3000
F. Overall length with bucket	mm	2950	3500	3500	3700	3700
G. Dumping angle at maximum height	°	40	40	40	40	40
H. Dumping height	mm	1920	2230	2230	2450	2450
I. Dumping reach	mm	720	715	715	700	700
J. Rollback of bucket on ground	°	30	30	30	30	30
K. Rollback of bucket at full height	°	104	104	104	104	104
L. Wheelbase	mm	1240	1500	1500	1500	1500
M. Ground clearance	mm	140	200	200	200	200
N. Angle of departure	°	20	20	20	20	20
O. Front turning radius without bucket	mm	1064	1298	1298	1365	1365
P. Front turning radius	mm	1825	2010	2010	2200	2200
Q. Rear turning radius	mm	1264	1714	1714	1742	1742
R. Rear axle to bumper	mm	594	890	890	938	938
S. Thread width	mm	1102	1462	1462	1654	1654
T. Width	mm	1402	1782	1782	1994	2124
U. Bucket width	mm	1500	1830	1830	2030	2160
