Overview

Specifications


Engine	Kubota D722
Rated power	7kw
Displacement	7.19ml/r
Bore stroke	3 cylinder, fan cool
Main Performance
Swing Speed (r/min)	12-13
Traveling Speed (km/H)	2.1/3.2km/h
Grade ability (%)	58%
Traveling Tracking Force (kN)	8.3
Bucket Digging Force (kN)	9
Arm Digging Force (kN)	5.5
Hydraulic System
Hydraulic system working pressure (Mpa)	20
Machine Weight (KG)	1400
Hydraulic pump flow (L/min)	18
Fuel Tank Capacity (L)	14.5
Hydraulic Tank Capacity (L)	14.5
Overall Dimensions
Overall Length (mm)	3329
Overall Width (mm)	990
Overall Height (mm)	2267
Counterweight Ground clearance (mm)	153
Axle Base (mm)	1190
Track width (mm)	200
Swing radius at tail (mm)	655
Swing radius at front (mm)	1812
Operation parameters
Bucket Capacity (m³)	0.023
Max. Digging Radius (mm)	3529
Max. Digging Depth (mm)	2017
Max. Digging Height (mm)	2955
Max. Dumping Height (mm)	2077
Max. vertical digging depth (mm)	1610
