Overview

Specifications


Engine	KD192F-1 E5
Rated power	7kw
Displacement	6.8ml/r
Bore stroke	single cylinder, fan cool
Main Performance
Swing Speed (r/min)	0-13
Traveling Speed (km/H)	2
Grade ability (%)	30°
Traveling Tracking Force (kN)	8.3
Bucket Digging Force (kN)	7.2
Arm Digging Force (kN)	4.6
Hydraulic System
Hydraulic system working pressure (Mpa)	16
Hydraulic Pump (Gear Pump)	Gear Pump
Hydraulic pump flow (L/min)	18
Fuel Tank Capacity (L)	26
Hydraulic Tank Capacity (L)	14.5 in Hydraulic tank 21.5 in Hydraulic system
Overall Dimensions
Overall Length (mm)	2840
Overall Width (mm)	880
Overall Height (mm)	2200
Counterweight Ground clearance (mm)	385
Axle Base (mm)	900
Track width (mm)	180
Undercarriage width (mm)	840
Undercarriage ground clearance (mm)	132
Operation parameters
Operation Weight (KG)	950
Bucket Capacity (m³)	0.023
Max. Digging Radius (mm)	3065
Max. Digging Depth (mm)	1715
Max. Digging Height (mm)	2600
Max. Dumping Height (mm)	1830
Tail Swing Radius(mm)	800
